(Example)
 IP address of this machine: 192.168.101.2
 Subnet mask: 255.255.255.0
 Gateway address: 192.168.101.1
When using a wired LAN, see "
1 Press the scroll button ▼ on the operator panel several times to select [Wireless(Infrastructure)
Setting], and press «OK».
2
Input the admin password using the numeric keypad, and press «OK».
Admin password
"It is not possible to use the wireless(AP Mode) at the same time." will be displayed for about 5 seconds.
3 Press ▲ to select [Enable], and press «OK».
4 Press ▼ to select [Network Setting], and press «OK».
5
Check that [IP Address Set] is selected, and press «OK».
6
Press ▼ to select [Manual], and press «OK».
7 Press «BACK», then press ▼ to select [IPv4 Address] on the [Network Setting] screen, and
finally press «OK».
Setting the IP address, etc.
- 45 -
".
