Printronix LP654C User Manual page 151

2
Load the paper with a size that can be set to a custom size into the tray to be used.
3
Check that "Ready To Print" appears on the display.
If the machine is in the power save mode, press «POWER SAVE» to restore.
4 Press the scroll button ▼ on the operator panel several times to select [Menus], and press
«OK».
5
Check that [Tray Configuration] is selected, and press «OK».
6
Press ▼ several times to select [Tray Setup] of the tray where the paper is loaded, and press
«OK».
7
Check that [Media Size] is selected, and press «OK».
8
Press ▼ several times to select [Custom], and press «OK».
9
Press «BACK».
10 Press ▼ to select [X Dimension], and press «OK».
11
Input the X dimension using the numeric keypad, and press «OK».
12
Press «BACK».
13 Press ▼ to select [Y Dimension], and press «OK».
14
Input the Y dimension using the numeric keypad, and press «OK».
15
Press «ON LINE» to return to the standby screen.
Printing from a PC
For Windows PCL printer driver
1
Open the "Devices and Printers".
How to open the printer folder
2
Right-click on the icon [PRINTRONIX LP654C PCL6], and select [Printing preferences].
3
Click [Paper Feed Options] in the [Setup] tab.
4
Click [Custom Size].
5
Input a name for the new size in [Name].
6
Input values in [Width] and [Length].
7
Click [Add] to save any media size in the list, and click [OK].
Up to 32 settings can be saved.
8
Click [OK] until the [Printing preferences] screen is closed.
9
Open the file to be printed.
10
Select [Print] from the [File] menu.
11
Click [Preferences].
12
Select the media size registered in [Size] on the [Setup] tab.
13
Specify the media weight and other settings as necessary, and click [OK].
14
Click [Print] in the [Print] screen.
