Using Snmpv3; Using Ieee802.1X (Wired Lan) - Printronix LP654C User Manual

12
When the [E-mail Alert Settings] screen is displayed, select appropriate settings in [Way of E-
mail Alerting], and click [To STEP2].
When you select [Upon occurrence of an event], an error is notified just once.
When you select [Periodically], an error is notified periodically until it is cleared.
13
Configure the settings following the on-screen instructions.
14
Click [OK].
15
Click [View a summary of current configuration] to check the current settings, and click [X] to
close the window.
You can also check the current settings of up to two addresses in the home window. Select the address
you want to check from the list.
16
Click [Submit].
The new settings will take effect after the network function of the machine has been reset.
 If no notification target error occurs, the notification e-mail will not be sent.

Using SNMPv3

By using the SNMP manager that is compatible with SNMPv3, the management of this machine can be
encrypted with SNMP.
1
Open the web page of this machine.
Opening the web page
2
Log in as an administrator.
Logging in as an administrator
3
Select [Admin Setup].
4
Select [Network] - [SNMP] - [Settings].
5
Configure the settings following the on-screen instructions.
6
Click [Submit].
The new settings will take effect after the network function of the machine has been reset.
 You can use a commercially-available SNMP manager to verify and change the settings of this machine. For the MIB
of this machine, refer to the supplied DVD, and check the MIB definition file in the [Misc] - [MIB Files] folder.

Using IEEE802.1X (Wired LAN)

This machine is compatible with IEEE802.1X authentication. IEEE802.1X authentication is possible after
IEEE802.1X authentication on the web page of this machine is enabled and the authentication switch is
connected.
Setting with EAP-TLS
This section describes how to set up EAP-TLS, one of the IEEE802.1X authentication.
- 214 -
