Item
Media Type (Fn93)
Media Weight (Fn94)
Tray Usage (Fn95)
Tray1 Config Paper Size (Fn10)
X Dimension (Fn11)
Y Dimension (Fn12)
Media Type (Fn13)
Media Weight (Fn14)
Tray2 Config Paper Size (Fn20)
X Dimension (Fn21)
Y Dimension (Fn22)
Media Type (Fn23)
Media Weight (Fn24)
Other Size
Tray3 Config Paper Size (Fn30)
X Dimension (Fn31)
Factory
default
settings
Plain Sets the type of paper that you want to print
on from the MP tray.
Light Sets the weight of the paper that you want
to print on from the MP tray.
When Sets how to use the MP tray. The available
Mismatching values are as follows.
[Normal Tray]: Treats the MP tray as a
normal tray like Tray 1 or Trays 2 - 4
(optional).
[When Mismatching]: Prints from the MP
tray with the correct paper loaded when the
paper loaded in the specified tray for
printing is different from the paper size of
the print data.
[Do Not Use]: Ignores the MP tray in
selecting or switching the tray automatically.
*1
A4 or Letter Sets the size of the paper you want to print
on from Tray 1.
210 Sets the paper width when you have
millimeter or selected a custom size for the paper that
*2
8.5 inch you want to print on from Tray 1.
297 Sets the paper length when you have
millimeter or selected a custom size for the paper that
*2
11.0 inch you want to print on from Tray 1.
Plain Sets the type of the paper you want to print
on from Tray 1.
Light Sets the weight of the paper you want to
print on from Tray 1.
Cassette Sets the size of the paper you want to print
Size on from Tray 2.
For [Cassette Size], follows the settings of
the paper size dial of the paper tray.
210 Sets the paper width when you have
millimeter or selected a custom size for the paper that
*2
8.5 inch you want to print on from Tray 2.
297 Sets the paper length when you have
millimeter or selected a custom size for the paper that
*2
11.0 inch you want to print on from Tray 2.
Plain Sets the type of the paper you want to print
on from Tray 2.
Light Sets the weight of the paper you want to
print on from Tray 2.
A5 [LEF] Specifies the paper size when the paper
size dial of Tray 2 is set to [OTHER].
Cassette Sets the size of the paper you want to print
Size on from Tray 3.
For [Cassette Size], follows the settings of
the paper size dial of the paper tray.
210 Sets the paper width when you have
millimeter or selected a custom size for the paper that
*2
8.5 inch you want to print on from Tray 3.
- 118 -
Description
