3-20 Intelligent Manageability
The following table lists the various keyboard light combinations, as well as the
meaning and action associated with each combination.
Num Lock 1
OFF
ON
OFF
ON
Writer: M. Church Project: Compaq Professional Workstation AP200 Reference Guide Comments: 352620-003
Table 3-3
Keyboard Light Combinations
Caps Lock 2 Scroll Lock 3
ON OFF
OFF OFF
OFF ON
ON ON
File Name: D-CH03.DOC Last Saved On: 1/19/99 9:39 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Meaning and Required Action
System requires Setup Password.
Enter the Setup Password. The light
remains turned on until you enter a valid
Setup Password.
System could not start from diskette
because the user ROMPaq diskette is
not present, is bad, or the drive is not
ready.
Insert a valid user ROMPaq diskette,
turn the power off, then turn the power
back on.
ROM upgrade failed.
Try another user ROMPaq diskette. If the
light remains turned on, contact
Compaq customer support.
ROM upgrade successfully completed.
Turn power off and back on to resume
normal system operation.
