Compaq Professional Workstation AP200 Reference Manual page 28

2-6 Software
View the product name, processor
type/speed/stepping, CPU serial number,
system ROM date, system board revision,
installed memory size, and asset tracking
number
Set the system time and date
View the currently installed drive A:
(preinstalled diskette drive) and drive B:
devices and set resources for diskette drives
Enable/disable diskette booting and diskette
writing
NOTE: After saving changes to Removable
Media, the workstation will restart. Turn the
workstation off, then on, manually.
View information regarding IDE devices
connected to the system
NOTE: ATAPI devices (CD-ROM, tape) are
listed as ATAPI devices.
Allows you to set hard drive to Ultra-DMA
(Ultra-ATA), EDMA, or PIO mode operation.
Enables/disables IDE drive translation
Specify the boot order of installed peripheral
devices (such as LS-120 drive, diskette drive,
hard drive, SCSI, or CD-ROM devices)
Set the energy saver mode to Advanced,
Disabled, or Minimal
Writer: M. Church Project: Compaq Professional Workstation AP200 Reference Guide Comments: 352620-003
Table 2-1
Computer Setup
Task
File Name: C-CH02.DOC Last Saved On: 12/15/98 4:21 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Computer Setup Selection
Select File, then select System
Information.
Select File, then select Set Time and
Date.
Select Storage, then select Diskette
Drives.
Select Storage, then select Removable
Media.
Select Storage, then select IDE Devices.
Select Storage for the IDE Drive Timing.
Select Storage for the IDE Drive
Translation.
Select Storage, then select Boot Order.
Select Power, then select Energy Saver.
Continued
