Chapter 3 Components and Power Supply
The following chapter provides detailed information on the Teldat Connect-4GePlus chassis and its components.
This information includes:

• Components.

• Information on assembly.
• Power supply.
• RESET button.
• Data connection.
• SIM card installation.
3.1 Components

3.1.1 Top Panel

The following figure shows the top panel.
Top Panel
Fig. 1:
The top panel components are as follows:
Top panel components
Item
A
The LED panel provides information on the status of the components (indicating whether they are active or not) and
on network activity.
LEDs
LED
PWR
Teldat Connect-4GePlus
Description
LED panel.
Status
Monochrome green
Description
Green -> Device powered.
