Technical Information
CONNECTOR
SIM Slots
ANTENNA
A.5.5.1 Antenna connectors and bands
Bands used for each antenna connector
Antenna connectors
Connector
3G /
WCDMA
4G /
LTE
5G-NR /
FR1
Comments
• LB (Low Band): 617–960 MHz
• MHB (Middle High Band): 1452–2690 MHz
• UHB (Ultra High Band): 3400–3800 MHz
• n77/n78: 3300–4200 MHz
• n79: 4400–5000 MHz
• LAA (License Assisted Access): 5150-5925 MHz
• TX: Transmit
• PRX: Primary Reception
• DRX: Diversity Reception
34
Note
The presented data rates are theoretical only, and the actual value
depends on network conditions.
• LTE:
• DL Cat 19 (Up to 1.6Gbps)
• UL Cat 18: 2CC intra-band contiguous and inter-band, 256QAM (Up to 200
Mbps)
• Supported BW: 1.4–20 MHz, per 3GPP specs for supported bands
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
Four SMA connectors.
1 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
Devices equipped with this interface are shipped with four (5G) multi-band swivel-
mount dipole antennas.
ANT4 ANT3
LB TX1/DRX & MHB MHB TX1/DRX MIMO
DRX & UHB DRX & UHB TX0/PRX
MIMO &LAA DRX
- Refarmed: LB TX1 / - Refarmed: MHB TX1 /
DRX & MHB DRX & DRX MIMO & UHB-
UHB DRXMIMO TX0/PRX
- n41 DRX - n41 TX1/DRX MIMO
- n77/n78/n79 DRX - n77/n78/n79
MIMO TX0/PRX
ANT2 ANT1
LMB DRX LMB TRX
MHB PRX MIMO & LB TX0/PRX & MHB
UHB PRX MIMO & TX0/PRX & UHB
LAA PRX TX1/DRX
- Refarmed: MHB PRX - Refarmed: LB TX0 /
MIMO & UHB PRX PRX & MHB TX0 /PRX
MIMO &UHB TX1/DRX
- n41 PRX MIMO - n41 TX0/PRX
- n77/n78/n79 PRX - n77/n78/n79
MIMO TX1/DRX
