3 Components and Power Supply
Side panels
Fig. 6:
The connectors are as follows:
Side panel connectors
Item
A
B
C

3.2 Mounting an anti-theft security cable

Teldat Connect-FW5G devices have been equipped with a standard Kensington security slot to which a security
cable can be attached. The T-bar lock of the security cable allows the device to be attached to an anchor point, thus
preventing potential thefts.
The security slot is located on the rear panel of the housing, as shown in the following figure:
Security Slot
Fig. 7:
8
Description
Kensington security slot
For further information, please see on page .
SIM Card. Slot where you can insert the SIM card.
Refer to Installing the SIM card
tion.
Cell connectors: ANT3 and ANT4.
For more information on the Cellular interface, refer to:
- WWAN antenna connection
- WWAN connector on page 29
- Wireless WAN interface on page 34
on page 19 for more information on SIM installa-
on page 17
