1-3 Mainboard Specification Table

85DR2-DC/85DR2-DCL Specifications and Features
CPU
North Bridge
South Bridge
BIOS
Memory
I/O Chip
AGP Interface
Audio
IDE Interface
PCI Slots
I/O Connectors
Other Feature
Models
Optional
Features
LAN Controller
on board
Socket 478B for P4 CPU
(Hyper Threading CPU and Prescott CPU included)
Intel 845E, supporting 533/400MHz FSB
Intel ICH4
AMI BIOS
Supporting DDR 266 DRAM, up to 2GB in 2 DDR
DIMM slots
W83627HF, with Hardware Monitor
AGP 4X mode only
AC'97 Audio 2.2 compliant, 2/6 channel audio
2 UATA 66/100 IDE ports
5 PCI Master slots on board
6 USB V2.0, 1 FDD port, 2 COM ports, 1 LPT,
1 IrDA, 1 PS/2 K/B, 1 PS/2 Mouse
Keyboard/Mouse Power On / Wake Up
85DR2-DC
No
13
Chapter 1 Specification
85DR2-DCL
Yes
