MODEL ATF™ PLUS Feeding System

Parts Listings

200# Hopper Components

Item Description
1* Hopper Cover (w/o hole)
Hopper Cover (w/ hole)
2 Tube Support Assembly
Clamp
Chain
3 Hopper Side (4 req'd
4 Boot Hanger
5 Hanger Bracket Assembly
6 Adjustment Bracket (2 req'd) 2706
7 Hair Pin
8 Clevis Pin, 5/16 x 1"
The 200# Hopper Assembly (w/o cover) may be
ordered under Part No. 7941.
The 200# Hopper Assembly (w/cover) may be
ordered under Part No. 28358.
*Both sides of the Hopper Cover and the
required hardware may be ordered under Part
No. 28206.

Feeder Line Components

Item Description
1* Auger
2 ATF Auger Tube (1-Hole Tube) 6684
ATF Auger Tube (2-Hole Tube) 6685
ATF Auger Tube (3-Hole Tube) 6686
3 Anti-Roost Bracket
4 Clamp
5 Line Charger
6 Hanger
7 Split Bolt
8 Spring
9 3/32" Cable
10 Charger Wire (165 ft.)
Charger Wire (165 ft.)
11 Poultry Trainer
12 3/8" Hex Nut
13 3/8" Flat Washer
*Round up to the nearest 10'. Auger lengths from
50 to 500 feet. Example: 6820-200 would be a
200' roll of Auger.
MF1814C
Part No.
28208
28702
14367
13948
2128-1
2680
2671
2681
2664
2797-1
Part No.
6820-0
29516
29520
29317
4207
6342
7551
4973
28994-165
28994-330
29333
1549
4976
Parts Listings
35
