Data Results - Micromeritics GEMINI VII KEYPAD Operator's Manual

2 Operational Procedures
D R
ATA ESULTS
Communications on page 3 - 34
Alt + 2
Press CHOICE to display the options. Press ENTER to select.
Data results for the last five analyses are saved in the analyzer's memory. These results can be
viewed using a web browser. To use this feature, connect a computer to the instrument's Ethernet
port.
These steps assume an IP address has already been assigned. If an address has not
been assigned, follow the steps in Communications to assign one.
1. Open a web browser.
2. Enter the IP address in the Address field of the web browser. This must consist of numbers
only, separated by a decimal.
3. Press Enter on the keypad. The analyzer serial number displays in the window—for
example, 107.
2 - 20
Gemini VII Keypad Operator Manual
239-42801-01 (Rev E) — July 2021
