C RS-232 O
PERATION
The Gemini analyzer is a standard DTE device. The RS-232 port on the back panel of the
analyzer can be used to attach an analytical balance for transfer of sample mass, or for
transmitting data through a serial line to a computer.
Ensure the receiving device is configured to interface with the assignments in the Pin Assignment
table. Any signals not listed will be ignored by the analyzer.
Pin Assignment
Pin
2
3
4
5
6
The Gemini uses the DTR and DSR signals for hardware flow control. Ensure the serial device
being used provides these signals. For example; if attaching to a computer (also a DTE device),
use a null modem cable which includes the signals designated in the above table. If there is a
problem with transmission, ensure that the signals are set up properly. If the signals are correctly
configured, contact the receiving device manufacturer for assistance.
Gemini VII Keypad Operator Manual
239-42801-01 (Rev E) — July 2021
Signal Description
RXD Receive data
TXD Transmit data
DTR Data terminal ready
GND Ground
DSR Data set ready
C RS-232 Operation
Data Direction
To analyzer
From analyzer
From analyzer
N/A
To analyzer
