3 Keypad Only Installations
D R
ATA ESULTS
Communications on page 3 - 10
Alt + 2
Press CHOICE to display the options. Press ENTER to select.
Data results for the last five analyses are saved in the analyzer's memory. These results can be
viewed using a web browser. To use this feature, there must be a connection to a network via an
Ethernet cable and a keyboard attached to a USB port.
These steps assume an IP address has already been assigned. If an address has not
been assigned, follow the steps in Communications to assign one.
1. Open a web browser.
2. Enter the IP address in the Address field of the web browser. This must consist of numbers
only, separated by a decimal.
3. Press Enter on the keypad. The analyzer serial number displays in the window - for
example, 107.
4. Click the serial number hyperlink. A last five analyses display in the window.
