Alt + 1
Some manual operations have been included in the software. These operations are used for
system testing and diagnostic purposes and should only be performed at the request of a service
representative.
Do not use this mode of operation without direction from a service representative.
Some operations when used incorrectly may cause damage to the instrument or one
of its components.
This template shows the keys used for manual mode functions.
When performing the manual control functions, pertinent information is displayed in the keypad
window. The following example shows the type of information that displays. A service
representative may request this information.
Gemini VII Keypad Operator Manual
239-42801-01 (Rev E) — July 2021
O
PERATIONS

Manual Mode Operations

A. Current Po reading (not applicable
for the 2390a)
B. Differential pressure
C. Servo valves
D. System valves
3 - 53
