6

SET MODE

Quick Set mode (Continued)
■
RTTY shift width
Sets the RTTY shift width to 170, 200, 425 or 850 Hz.
NOTE: 170 Hz is automatically set when the twin peak filter is ON.
RTTY key polarity
Sets the RTTY keying polarity to normal or reverse. When reverse polarity is selected, Mark and Space are re-
versed.
n (normal) : Key open/close = Mark/Space
r (reverse) : Key open/close = Space/Mark
■
Set mode
LCD Backlight
Set the brightness of the LCD to HI (High), Lo (Low) or oF (Off).
Beep
A beep sounds each time a key is pushed. This function can be turned OFF for silent operation.
on : The Confirmation beep is ON. ; oF : The Confirmation beep is OFF.
The volume level can be set in "Beep Level," as described below.
Band Edge Beep
A beep sounds when an operating frequency enters or exits an amateur band. This function is independent from
the "Beep" setting described above.
on : The Band edge beep is ON. ; oF : The Band edge beep is OFF.
The volume level can be set in "Beep Level," as described below.
Beep Level
Set the maximum volume level for the confirmation beep and band edge beep tones to between 0% and 100%,
in 1% steps.
When beep tones are set to OFF, this setting has no effect.
Beep Level Limit
Turn the beep tones output level limiting ON or OFF for the confirmation and band edge beep tones.
When this item is set to ON, the beep tones are linked to the [AF] control until rotation of the [AF] control reaches
to the specified level—further rotation will not increase the volume of the beep tones.
on : The Beep level is limited with the [AF] control. ; oF : The Beep level is linked to the [AF] control.
RF/SQL Control
Set as the RF/squelch control, the squelch control only (RF gain is fixed at maximum) or Auto (RF gain control in
SSB, CW and RTTY; squelch control in AM).
See pages 4, 31 for details.
rS (RF+SQL) : The [RF/SQL] control is set as the RF/squelch control.
Sq (SQL) : The [RF/SQL] control is set as the squelch control.
At (AUTO) : The [RF/SQL] control is set as the RF gain control in SSB, CW and RTTY; squelch control in AM.
29 29
(RTTY mode)
(RTTY mode)
170 Hz (default)
NORMAL (default)
High (default)
ON (default)
ON (default)
50% (default)
ON (default)
RF + SQL (default)
