IMPORTANT
READ THIS INSTRUCTION MANUAL CARE-
FULLY
before attempting to operate the transceiver.
SAVE THIS INSTRUCTION MANUAL.
manual contains important safety and operating in-
structions for the IC-7200.

FOREWORD

We understand that you have a choice of many differ-
ent radios in the market place. We want to thank you
for making the IC-7200 your radio of choice, and hope
you agree with Icom's philosophy of "technology first."
Many hours of research and development went into
the design of your IC-7200.
D FEATURES
❍ IF DSP features
❍ Digital Twin PBT
❍ Manual notch function
❍ ±0.5 ppm of high frequency stability
❍ Simple operation
❍ Tough and compact body
❍ Standard voice synthesizer

EXPLICIT DEFINITIONS

WORD
Personal death, serious injur y or an
RDANGER!
explosion may occur.
Personal injury, fire hazard or electric
RWARNING!
shock may occur.
Equipment damage may occur.
CAUTION
If disregarded, inconvenience only. No risk
NOTE
of personal injury, fire or electric shock.
Spurious signals may be received near the following
frequencies when the transceiver is connected to a PC
via an USB cable.
These are generated in the internal circuit and does
not indicate a transceiver malfunction:
21.0295 MHz, 51.0910 MHz, 51.0957 MHz
Icom, Icom Inc. and the Icom logo are registered trademarks of
Icom Incorporated (Japan) in Japan, the United States, the United
Kingdom, Germany, France, Spain, Russia and/or other coun-
tries.
Microsoft, Windows and Windows Vista are registered trademarks
of Microsoft Corporation in the United States and/or other coun-
tries.
All other products or brands are registered trademarks or trade-
marks of their respective holders.
i
This
DEFINITION

SUPPLIED ACCESSORIES

The transceiver comes with the following accessories.
q Hand microphone (HM-36) ........................... 1
w DC power cable (OPC-1457) ........................ 1
e Spare fuse (ATC 5 A) .................................... 1
r Spare fuse (ATC 30 A) .................................. 2
t Jack cap (for [PHONES]) ............................... 1
y ACC cable ....................................................... 1
u 3.5 (d) mm plug ............................................... 1
i 6.3 (d) mm Electronic keyer plug .................... 1
o CD .................................................................. 1
q w
y u

FCC INFORMATION

• FOR CLASS B UNINTENTIONAL RADIATORS:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV tech-
nician for help.
Caution: Changes or modifications to this transceiver, not
expressly approved by Icom Inc., could void your authority
to operate this transceiver under FCC regulations.
t
i o
