Icom IC-7200 Instruction Manual page 37

Main Dial Auto TS
Sets the auto tuning step function so that when rotating [DIAL] rapidly, the tuning step rate adapts as selected.
Set either HI (Fastest), Lo (Faster) tuning speed, or to oF (OFF).
HI : Approximately 5 times faster when the tuning step is set to 1 kHz or smaller steps; approximately 2 times
faster when the tuning step is set to 5 kHz or larger steps.
Lo : Approximately 2 times faster.
oF : Auto tuning step is turned OFF.
Dial ¼
Turn the ¼-speed tuning function ON or OFF in the CW, RTTY and SSB data modes.
on : The ¼-speed tuning function is ON for critical tuning. While operating in the CW/RTTY/SSB data modes, the
dial sensitivity is reduced to ¼ of normal.
oF : The ¼-speed tuning function is OFF.
NOTE: This function is only usable when the programmable tuning step is OFF (p. 14).
Mic Up/Down Speed
Sets the rate at which frequencies are scanned when the microphone [UP]/[DN] keys are used.
HI : High speed (50 tuning steps/second) ; Lo : Low speed (25 tuning steps/second)
SSB/CW Synchronous Tuning
Turns the displayed frequency shift function ON or OFF.
When this function is set to ON, the received signal will remain the same even when the operating mode is
changed between SSB and CW.
The amount of frequency shift will change according to the CW tone pitch setting.
on : The displayed frequency shifts when the operating mode is changed between SSB and CW.
oF : The displayed frequency does not shift.
CW Normal Side
Select the carrier point of CW mode between LSB and USB.
L (LSB) : LSB is the normal mode. ; U (USB) : USB is the normal mode.
Break-In
Selects the CW break-in type.
Full break-in (QSK) activates the receiver between transmitted dots and dashes. This is useful when operating
contests, when "fast responses" are common.
Semi break-in keeps the receiver quiet between dots and dashes, and automatically returns to receive after a
pre-set time after you stop keying.
When break-in is turned off, the key or paddle can generate side tones, selectable in the Quick Set mode, but will
not transmit.
oF : No break-in operation ; SE (Semi) : Semi break-in operation ; FL (Full) : Full break-in operation
Break-In Delay
Adjusts break-in delay time for CW semi break-in operation between 0.2 and 13.0 (dots), in 0.1 (dots) steps.
6
SET MODE
High (default)
OFF (default)
High (default)
OFF (default)
LSB (default)
OFF (default)
7.5 dots (default)
