FOR EUROPEAN VERSIONS
• Installation Notes
For amateur base station installations it is recom-
mended that the forward clearance in front of the an-
tenna array is calculated relative to the EIRP (Effective
Isotropic Radiated Power). The clearance height below
the antenna array can be determined in most cases
from the RF power at the antenna input terminals.
As different exposure limits have been recommend-
ed for different frequencies, a relative table shows a
guideline for installation considerations.
Below 30 MHz, the recommended limits are specified
in terms of V/m or A/m fields as they are likely to fall
within the near-field region. Similarly, the antennas
may be physically short in terms of electrical length
and that the installation will require some antenna
matching device which can create local, high inten-
sity magnetic fields. Analysis of such MF installations
is best considered in association with published guid-
ance notes such as the FCC OET Bulletin 65 Edition
97-01 and its annexes relative to amateur transmitter
installations.
The EC recommended limits are almost identical to
the FCC specified 'uncontrolled' limits and tables ex-
ist that show pre-calculated safe distances for different
antenna types for different frequency bands. Further
information can be found at http://www.arrl.org/.
• Typical amateur radio installation
Exposure distance assumes that the predominant ra-
diation pattern is forward and that radiation vertically
downwards is at unity gain (sidelobe suppression is
equal to main lobe gain). This is true of almost every
gain antenna today. Exposed persons are assumed
to be beneath the antenna array and have a typical
height of 1.8 m.
The figures assume the worst case emission of a con-
stant carrier.
For the bands 10 MHz and higher the following power
density limits have been recommended:
10–50 MHz
2 W/sq m
Vertical clearance by EIRP output
1 Watts
2.1 m
10 Watts
2.8 m
25 Watts
3.4 m
100 Watts
5 m
1000 Watts
12 m
Forward clearance by EIRP output
100 Watts
2 m
1000 Watts
6.5 m
10,000 Watts
20 m
100,000 Watts
65 m
In all cases any possible risk depends on the trans-
mitter being activated for long periods. (actual recom-
mendation limits are specified as an average during 6
minutes) Normally the transmitter is not active for long
periods of time. Some radio licenses will require that a
timer circuit automatically cuts off the transmitter after
1–2 minutes or so.
Similarly some modes of transmission, like SSB, CW
and AM, have a lower 'average' output power and the
assessed risk is even lower.
• Country codes List
Country
Codes
1
Austria
AT
2
Belgium
BE
3
Bulgaria
BG
4
Croatia
HR
5
Czech Republic
CZ
6
Cyprus
CY
7
DK
Denmark
8
Estonia
EE
9
FI
Finland
10
FR
France
11
DE
Germany
12
GR
Greece
13
HU
Hungary
14
IS
Iceland
15
IE
Ireland
16
IT
Italy
17
LV
Latvia
(ISO 3166-1)
Country
Codes
18
Liechtenstein
LI
19
LT
Lithuania
20
Luxembourg
LU
MT
21
Malta
22
NL
Netherlands
23
Norway
NO
24
PL
Poland
25
PT
Portugal
26
RO
Romania
27
SK
Slovakia
28
SI
Slovenia
29
ES
Spain
SE
30
Sweden
31
CH
Switzerland
32
TR
Turkey
33
GB
United Kingdom
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
42
