Systems Insight
Display LED and
color
DIMM (amber)
DIMM (amber)
Over temp (amber)
Over temp (amber)
PCI riser (amber)
Fan (amber)
Fan (amber)
Power supply
(amber)
Power supply
(amber)
Power cap (off)
Power cap (green)
Power cap (green)
Health LED
Red
Amber
Amber
Red
Red
Amber
Red
Red
Amber
Hitachi Advanced Server HA810 G2 User Guide
System power
LED
Green One or more DIMMs have failed.
DIMM in slot X is in a pre-failure
Green
condition.
Green The Health Driver has detected a
cautionary temperature level.
Amber The server has detected a
hardware critical temperature
level.
Green The PCI riser cage is not seated
properly.
One fan has failed or has been
Green
removed.
Green Two or more fans have failed or
been removed.
Amber Power supply (amber) Red
Amber One or more of the
following conditions might exist:
•
•
•
Green One or more of the following
conditions might exist:
•
•
•
•
Amber Standby
Flashing green Waiting for power
Green Power is available
Status
Only one power supply is installed,
and that power supply is in standby.
Power supply fault.
System board fault.
Redundant power supply is
installed and only one power
supply is functional.
AC power cord is not plugged
into redundant power supply.
Redundant power supply fault.
Power supply mismatch at
POST or power supply
mismatch through hot-plug
addition.
