Table 44: SC650T-NA Current Consumption
Parameter Description
OFF state
LTE-FDD supply
current
I
VBAT
LTE data transfer
Table 45: SC650T-EM Current Consumption
Parameter Description
OFF state
LTE-FDD supply
I
VBAT
current
LTE data transfer
SC650T_Hardware_Design
Conditions
Power down
Sleep (USB disconnected)
@DRX=6
Sleep (USB disconnected)
@DRX=8
Sleep (USB disconnected)
@DRX=9
LTE-FDD B2 @max power
LTE-FDD B4 @max power
LTE-FDD B5 @max power
LTE-FDD B7 @max power
LTE-FDD B12 @max power
LTE-FDD B13 @max power
LTE-FDD B14 @max power
LTE-FDD B25 @max power
LTE-FDD B26 @max power
LTE-FDD B66 @max power
Conditions
Power down
Sleep (USB disconnected)
@DRX=6
Sleep (USB disconnected)
@DRX=8
Sleep (USB disconnected)
@DRX=9
LTE-FDD B1 @max power
Smart LTE Module Series
SC650T Hardware Design
Min Typ. Max
73
5.3
3.5
3.2
591
566
540
654
541
561
532
588
571
631
Min Typ. Max
80
5
3.2
2.9
650
98 / 131
Unit
uA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
Unit
uA
mA
mA
mA
mA
