LiNX® Control System

9 Technical Data

9.1 Technical Specifications

9.1.1 Mechanical Specifications

Permissible Operating, Storage and Humidity Conditions
Temperature range for operation according to
ISO 7176-9:
Recommended storage temperature:
Temperature range for storage according to ISO
7176-9:
Operation humidity range according to ISO 7176-
9:
Degree of protection:
1 IPX4 classification indicates the electrical system is protected against spray water.

9.1.2 Electrical Specifications

Parameter
Operating voltage (Vbatt)
Idle current
Quiescent current (power off)
92
-13°F (-25°C)-122°F (+50°C)
59°F (15°C)
-40°F (-40°C)-149°F (+65°C)
0–90% RH
1
IPX4
Operating Forces
Joystick 1.9 N
Minimum Nominal
17 24
- 70
- -
Maximum Units
34 V
- mA at 24V
0.23 mA at 24V
60126081-C
