3. Tap button E to close the Menu screen.
Screen lock is activated.
Turn the remote off and on (power-cycle) to
deactivate the screen lock.
Keep the touch screen dry to ensure proper response
during use.

6.2 Navigating User Function Screens

User function screen navigation depends on how the
Navigation button is configured. Refer to 4.4 Navigation Button,
page 17, for more information about possible configurations.
You can locate and select a function screen by navigating
through the programmed profiles and functions. Navigation
depends on your needs and abilities and include the following
methods:

Direct navigation

l
Indirect navigation
l
60126081-C

6.2.1 Function Change Inhibits

Function change blocked is a safety feature that prevents
accidental driving or seating movements when:
a function change should be carried out when the user
l
performs an action on the active function.
The user must finish the current action to change the function.
Otherwise, a function change blocked overlay displays.
6.2.2 Direct Navigation
To navigate profiles and functions, move from an active
function screen to an adjacent function screen. The function
screen immediately becomes active.
Direct navigation is not performed with an active
user input (for example, the remote) because the
active user input is used to operate only the
active function screen (for example, moving the
remote to drive); instead, the user navigates
through the profiles and functions using the touch
screen or other control inputs.

Using Swipe-and-Tap Mode

Changing Function Screens
1. Swipe over the screen or tap the Navigation button to
open the screen preview display.
2. Swipe left or right to change function screens.
3. Tap the selected function screen, tap the Navigation
button or wait several seconds to activate the selected
function screen.
6 Usage
31
