LiNX® Control System

Egg Switch

The egg switch alternates powered seating functions of the
following single power configurations:
Powered recline only
l
Powered seat tilt only
l
Center-mount elevating legrest (LNX) only
l
1. Make sure the mobility device is on a level surface and is
turned on.
2. Press and hold the tagged area of the egg switch to run
the powered seating function.
3. Release the egg switch if the desired seating position is
reached.
If the egg switch is pressed again within three seconds, the
powered seating function moves in the same direction.
4. To alternate direction, press the egg switch after it has
been released for more than three seconds.

Stereo Toggle Switch

The stereo toggle switch alternates powered seating functions
of the following single power configurations:
Powered recline only
l
Powered seat tilt only
l
Center-mount elevating legrest (LNX) only
l
1. Make sure the mobility device is on a level surface and is
turned on.
56
2. Deflect and hold the toggle switch up A or down B to
move a particular seating function.
The seating function moves as long as the toggle switch is
deflected.

Stereo Button Switch

The stereo button switch alternates powered seating functions
of the following single power configurations:
Powered recline only
l
Powered seat tilt only
l
Center-mount elevating legrest (LNX) only
l
1. Make sure the mobility device is on a level surface and is
turned on.
2. Press and hold the stereo buttons A or B to move a
particular seating function.
The seating function moves as long as the button is
pressed.
4–way Toggle Switch
1. Make sure the mobility device is on a level surface and is
turned on.
2. Deflect and hold the toggle switch in the appropriate
direction to move a particular seating function.
The seating function moves as long as the toggle switch is
deflected.
See the following tables for direction and powered seating
function combinations.
