LiNX® Control System
If the Navigation entry is set to First Profile, the menu
l
selection starts at the first profile in the Profile menu. You
select a profile before moving into the selected profile's
Function Screen menu. You can then select a function
screen from the Function Screen menu or return to the
Profile menu to select a different profile.
If Navigation entry is set to Active User Function, the
l
menu selection starts at the currently selected function
screen in the Function Screen menu. From there you can
choose to navigate the Function Screen menu, select a
function screen or move to the Profile menu and select a
different profile.

Menu Select with 4Q Operation

1. Press the external switch.
The Profile menu opens.
2. Give forward input A or reverse input B to switch
between profiles.
3. Give right input D to select the profile.
The Function Screen menu opens.
4. Give forward input A or reverse input B to switch
between function screens.
5. Give left input C to switch back to the previous menu.
36
6. Give right input D to select the function screen.

Menu Select with 3Q Operation

1. Press the external switch.
The next function screen displays.
2. Press the external switch again to switch through all the
function screens in the profile.
When all function screens are switched through, the
Profile menu opens.
3. Give right input A to change the profile.
4. To close the profile menu, give right input until the Close
button B is selected.
Give left input to close the profile menu.
5. Give left input C to select the profile.
Give right input A to change the function screen.
