4.4 Navigation Button

Depending on the configuration of the remote module and the user's needs, the navigation button displays on the bottom-left or
bottom-right of the screen.
When activated, the navigation button changes color from grey to blue.
The navigation button has two important functions:
1. A visual indication of the configured interaction mode.
This means swiping and tapping the screen activates different functions.
This means only tapping the screen activates different functions. Swipe inputs are ignored.
For more information about changing the interaction mode, refer to 6.1.7 Menu Screen, page 29.
2. A navigation function, depending on context and activation duration. For example, while viewing an active user function
screen, a short press on the Navigation button opens the screen preview display. Refer to 6.2 Navigating User Function
Screens, page 31. A long press opens the status screen. Refer to 6.1.7 Menu Screen, page 29.
External inputs can also be used to interact with the system. Refer to 6.19 Secondary Inputs, page 71.

4.5 Labels on the Product

4.5.1 Labels on Dynamic Controls' Parts

Labels of Dynamic Controls' parts are located on the rear side of the part. Depending on the part, not all labels are available.
Fig. 4-3 Rear side of the DLX-REM400
60126081-C
Configured for swipe-and-tap actions
Configured for tap actions
Fig. 4-4 Rear side of the DLX-IN400 input module
