LiNX® Control System
For operating the powered seating functions, refer to 6.16.1
Through Seating Screens, page 54.

Operating the Lighting Functions and Horn

Via a utility function screen, you are able to operate the lighting
functions with an external input. The utility function screen is
part of one or more profiles and can be activated like a drive or
seating function screen.
1. Activate the utility function screen.
2. Give an input to the front A to turn on the horn.
3. Give a short input to the right B to turn on/off the
position lights.
4. Give a short input to the left C to turn on/off the hazard
lights.
5. Give a long input to the left or right D to turn on/off the
left or right turn signal.
Activate a drive function screen to drive normally
while the position and hazard lights remain turned on.
After more than 10 seconds, the turn signals turn off.

6.19.2 Using the Compact Single Switch Joystick

Driving

1. Deflect the joystick from the neutral position to drive in
the desired direction.
72
For more information about driving, refer to 6.5 Using
Proportional Driving Mode, page 41.

Changing Function Screens

For information about the difference between the
function screen and the profile, refer to 4.3 User
Function Screen Overview, page 13.
1. Short press the joystick button A to change the function
screen.
2. Long press the joystick button A to change the profile.
For information about operating powered seating functions,
refer to 6.16.1 Through Seating Screens, page 54.
Operating the Lighting Functions and Horn
Via a utility function screen, you are able to operate the lighting
functions with an external input. The utility function screen is
part of one or more profiles and can be activated like a drive or
seating function screen.
1. Activate the utility function screen.
2. Give an input to the front A to turn on the horn.
60126081-C
