LED indicators
The available LED indicators are the following:
Ref#
Use
1
POWER:
- LED ON: ReliaGATE powered by the external source
- LED OFF: ReliaGATE not powered by the external source
2
CELL (Cellular modem activity):
- LED ON means modem ON;
- LED blinking means modem attached to GSM network
3
USER1 (General purpose)
4
USER2 (General purpose)
To manage the USER LEDs see
Figure 9.3 - LED indicators layout
Table 9.3 - LED indicators description
"LED indicators" on page
42.
9 Product interfaces
Color
Blue
Green
Green / Amber
Green / Amber
25
/ 62
