- Page 1 USER MANUAL Re liaGATE 10-10 Mini Gateway Rev 1.5 – 2 April 2014 – REGATE-10-10_UsrMan_EN_1.5...
-
Page 2: Trademarks
Trademarks All trademarks both marked and unmarked appearing in this document are the property of their respective owners. Revision history Revision Description Date First release 2 April 2014 © 2014 Eurotech... -
Page 3: Table Of Contents
ReliaGATE 10-10 User Manual Table of contents Table of contents Trademarks .................................. 2 Revision history ................................2 Table of contents ................................3 Important user information ............................5 Alerts that can be found throughout this manual ......................5 Safety notices and warnings ............................6 Do not operate in an explosive atmosphere ...................... - Page 4 Table of contents ReliaGATE 10-10 User Manual Optoinsulated inputs ............................22 Bluetooth ..................................23 Example of connections ............................. 24 LED indicators ................................25 Embedded Linux ................................. 26 Developing applications ............................. 26 Installing the downloaded toolchain archive ......................26 Appendix A - Reference information ......................... 27 Product information ..............................
-
Page 5: Important User Information
Eurotech reserves the right to revise this document or to make changes to its content at any time without any obligation to notify any person of such revision or changes. -
Page 6: Safety Notices And Warnings
Eurotech assumes no liability for the customer’s failure to comply with these requirements. The safety precautions listed below represent warnings of certain dangers of which Eurotech is aware. You, as the user of the device, should follow these warnings and all other safety precautions necessary for the safe operation of the device in your operating environment. -
Page 7: Installation
• Never open, dismantle or repair the device! • For your maintenance or repair requirement please contact a qualified Eurotech engineer. If the device does not function correctly and you are unable to find a solution, feel free to contact the Eurotech Technical Support Team. -
Page 8: Life Support Policy
ReliaGATE 10-10 User Manual Life support policy WARNING! Do not use Eurotech products as critical components of life support devices or systems without the express written approval of Eurotech Spa. Warranty Please contact your local Eurotech Sales Office for detailed warranty terms and conditions. -
Page 9: Fcc Information And Compliance
ReliaGATE 10-10 User Manual Important user information FCC information and compliance This equipment complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 10: Technical Assistance
For any technical questions, or if you cannot isolate a problem with your device, or for any enquiry about repair and returns policies, feel free to contact your local Eurotech Technical Support Team (see the last page of this manual for details). -
Page 11: Label Location
ReliaGATE 10-10 User Manual Label location Label location The product labels are placed on the bottom of the device. REGATE-10-10-xx LABEL FCC Disclaimer LABEL REGATE-10-10_UsrMan_EN_1.5... -
Page 12: Product Overview
This allows for simpler and faster programming, and transparent portability across a variety of hardware platforms. EDC is a complete and scalable infrastructure that enables Eurotech devices to send and receive data to the cloud, that can then be accessed by user-designed components and applications. -
Page 13: Product Interfaces
ReliaGATE 10-10 User Manual Product interfaces Product interfaces * Antennas can be external or internal according to product versions REGATE-10-10_UsrMan_EN_1.5... -
Page 14: Product Specifications
• FCC • FCC SW FEATURES • Linux Yocto Operating system • M2M Device Software Framework v 2.0 • Fully manageable through Eurotech M2M Platform • ESF ready • EDC ready Telit HE910-EUD module Telit HE910-NAD module Simcom SIM900 module... -
Page 15: Make The Connections
ReliaGATE 10-10 User Manual Make the connections Make the connections To get started with your ReliaGATE 10-10 you can use the screw-type connector on the rear side and connect: • Power supply SIGNAL PIN# Input Voltage • Serial console SIGNAL PIN# RS232 TX RS232 RX... -
Page 16: Perform The Boot Sequence
Perform the Boot Sequence ReliaGATE 10-10 User Manual Perform the Boot Sequence 1. Give power. The boot sequence begins 2. The CPUs initial program loader starts 3. The secondary program loader (SPL) is loaded from the first block on the NAND flash. The purpose of the SPL is to bootstrap the system such that Uboot can be loaded and executed 4. -
Page 17: Hardware Features
ReliaGATE 10-10 User Manual Hardware features Hardware features ReliaGATE 10-10 block diagram REGATE-10-10_UsrMan_EN_1.5... -
Page 18: Am335X Processor
Hardware features ReliaGATE 10-10 User Manual AM335x processor The ReliaGATE 10-10 is based on the TI OMAP AM3352 processor: http://www.ti.com/lit/ds/symlink/am3359.pdf The processor is an integrated system-on-a-chip microprocessor for high performance, low-power portable handheld and handset devices. It incorporates on-the-fly voltage and frequency scaling and sophisticated power management. -
Page 19: Watchdog Timer
ReliaGATE 10-10 User Manual Hardware features Watchdog timer The ReliaGATE 10-10 uses an internal watchdog timer from the AM335x CPU, which can be used to protect against erroneous software. The watchdog is mapped to the /dev/watchdog device under Linux. The timeout is pre-programmed to 48seconds approximately. -
Page 20: Telit He910-Eud
Hardware features ReliaGATE 10-10 User Manual Telit HE910-EUD DESCRIPTION FEATURE EMEA/APAC/Latin America Market • GSM / GPRS / EDGE: 850, 900, 1800, 1900 Supported • UMTS / HSPA: 800/850*, 900, 2100 MHz Frequencies * Bands B6 and B19 (800 MHz) are a subset of B5 (850 MHz) and supported as well HSPA+ data up to: Data •... -
Page 21: Usb
Under Linux, Station mode is supported using wpa_supplicant. wpa_supplicant howto • Under Linux, Access Point mode is supported using hostapd. By default Wi-Fi is not enabled (unless you are running ESF). http://esf.eurotech.com/doc/ESFDevGuide/latest/1.01-Product-Overview.asp MAIN FEATURES • IEEE 802.11 2.4 GHz b/g/n •... -
Page 22: Serial Com Ports
Hardware features ReliaGATE 10-10 User Manual Serial COM ports The AM335x processor provides 6 high-speed, fully functionally compatible 16550 serial UARTs on the ReliaGATE 10-10. Four of these channels can be used as follows: Address Function Port 0x44e09000 Console ttyO0 0x48022000 Not used ttyO1... -
Page 23: Bluetooth
ReliaGATE 10-10 User Manual Hardware features Bluetooth The ReliaGATE 10-10 can provide a Bluetooth v2.1 interface. Example of code: BLUETOOTH() print_title " BLUETOOTH TEST " Running=`ps aux | grep uim -c` if [ "$Running" -eq 1 ]; then uim & print_timeout 5 "Starting UIM Bluetooth manager ..."... -
Page 24: Example Of Connections
Example of connections ReliaGATE 10-10 User Manual Example of connections The following diagram shows the screw terminal connections in the ReliaGATE 10-10 REGATE-10-10_UsrMan_EN_1.5... -
Page 25: Led Indicators
ReliaGATE 10-10 User Manual LED indicators LED indicators There are 3 user LED indicators on the ReliaGATE 10-10, accessible via an I2C GPIO expander IC at address 0x41. Example BASH script I2C_LEDS() printf "I2C LEDS TEST " echo "Setting up the I2C GPIO expander for output" i2c-regs -d /dev/i2c-2 0x41 3 0 echo "Observe the LEDS connected to D0 - D2"... -
Page 26: Embedded Linux
Embedded Linux ReliaGATE 10-10 User Manual Embedded Linux The version of Linux running on the ReliaGATE 10-10 is based on POKY Linux which is part of the Yocto Project. https://www.yoctoproject.org/ Developing applications Learning how to create Yocto BSPs and using them effectively can be a time-consuming and complex process. It is possible and often desirable therefore to build projects outside of the main poky build system. -
Page 27: Appendix A - Reference Information
ReliaGATE 10-10 User Manual Appendix A - Reference information Appendix A - Reference information Product information Product notices, updated drivers, support material, 24hr-online ordering: www.eurotech.com SDIO card information SD Card Association and product information: www.sdcard.org www.sdcard.com USB information Universal Serial Bus (USB) specification and product information: www.usb.org... - Page 28 (This page has been intentionally left blank)
-
Page 29: Notes
ReliaGATE 10-10 User Manual Notes Notes REGATE-10-10_UsrMan_EN_1.5... - Page 30 Tel: +33 04.72.89.00.90 Fax: +33 04.78.70.08.24 E-mail: sales.fr@eurotech.com E-mail: support.fr@eurotech.com Web: www.eurotech.com For your local contact please refer to: www.eurotech.com/contacts Specifications and features are subject to change without notice. All trademarks and trade names are the property of their respective owners.
