Table Of Contents - Eurotech ReliaGATE 10-05-34 Original User Manual

ReliaGATE 10-05-34 User Manual Rev 1-0
T
ABLE OF CONTENTS
Trademarks
Revision history
Table of contents
1 Important Information
1.1 Signals used in this document
1.2 Disclaimer of liability
1.3 Intended audience
2 Safety Instructions
2.1 Observe antistatic precautions
2.2 Connect power supply correctly
3 How to receive technical assistance
3.1 How to receive technical support
4 Conventions used in this document
4.1 Conventions for signal names
4.2 Abbreviations for direction and electrical characteristics of a signal
5 Product overview
5.1 Product labels
6 Declaration of Conformity
6.1 FCC Class A notice
6.2 RoHS compliance
6.3 WEEE compliance
7 Technical Specifications
8 Getting started
9 Product interfaces
9.1 Front panel interfaces
9.1.1 DIP switch selector functions
9.1.2 8-position connector functions
9.2 Rear panel interfaces
9.3 LED indicators
9.4 Service panel interfaces
10 Interfaces in detail
10.1 Power supply
10.1.1 Power supply parameters
10.1.2 Power supply connector pinout
10.1.3 How to turn ON the ReliaGATE 10-05-34
10.1.4 How to turn OFF the ReliaGATE 10-05-34
10.1.5 How to manage the ReliaGATE 10-05-34 power consumption
10.1.6 How to perform a power reset of the ReliaGATE 10-05-34
10.2 Wi-Fi and Bluetooth
10.2.1 Wi-Fi specifications
10.2.2 Bluetooth specifications
10.3 Cellular
10.4 The MicroSIM card receptacle
10.5 Ethernet port
