ReliaGATE 10-05-34 User Manual Rev 1-0
12 H
OW TO ACCESS THE INTERFACES UNDER
12.1

Ethernet port

On the rear panel, the ReliaGATE 10-05-x4 exposes one 10/100 Mbps Ethernet port for wired network
connectivity:
Ethernet 0 port, referenced as eth0
l
12.2

Wi-Fi and Bluetooth

On the rear panel, the ReliaGATE 10-05-x4 exposes an external antenna connection to fully implement Wi-
Fi 802.11b/g/n and Bluetooth 4.0 BLE functions:
The Wi-Fi interface is referenced as wlan0
l
The Bluetooth interface is referenced as hci0
l
12.3

Modem

By default the ReliaGATE 10-05-x4 exposes the modem as follows:
AT commands port (data communication):
l
To turn the modem OFF unconditionally, use the following commands:
echo 1 > /sys/class/gpio/gpio30/value
sleep 0.5
echo 0 > /sys/class/gpio/gpio30/value
To toggle the modem power status, use the following commands:
echo 1 > /sys/class/gpio/gpio60/value
sleep 5
echo 0 > /sys/class/gpio/gpio60/value
12.4

COM ports 0 and 1, Console port

The ReliaGATE 10-05-x4 exposes the COM ports as follows:
COM port 0: /dev/ttyO4 (
l
COM port 1: /dev/ttyO3 (
l
Console port /dev/ttyO0 (
l
12.4.1

How to test a COM port

Use the utility below to test the COM port. It works in either RS-232 or RS-485 mode.
This utility allows you to transmit/receive data to/from the COM port.
NOTE: this utility does not include a local echo (it does not allow you to see the sent data)
#connect ttyO3 with a baud rate of 9600
microcom /dev/ttyO3 –s 9600
available on the front panel)
available on the front panel)
available behind the service panel)

12 How to access the interfaces under Linux

/dev/ttyACM0
L
INUX
41
/ 62
