ReliaGATE 10-05-34 User Manual Rev 1-0
4 C
ONVENTIONS USED IN THIS DOCUMENT
4.1

Conventions for signal names

Convention
GND
#
_P
_N
4.2 Abbreviations for direction and electrical characteristics of
a signal
Convention
I
O
IO
P
A
3.3
5
NC
Reserved
Description
Digital ground plane
Active low signal
Positive signal in differential pair
Negative signal in differential pair
Description
Signal is an input to the system
Signal is an output from the system
Signal may be input or output
Power and ground
Analog signal
3.3 V signal level
5 V signal level
No Connection
Use is reserved to Eurotech

4 Conventions used in this document

13
/ 62
