Memory Map

The ADSP-BF518F processor has internal static random access memory
(SRAM) used for instructions and data storage. See
nal memory details can be found in the ADSP-BF51x Blackfin Processor
Hardware Reference.
The ADSP-BF518F EZ-Board includes four types of external memory:
synchronous dynamic random access memory (SDRAM), serial peripheral
interconnect (SPI) flash, parallel flash, and eMMC. See
more information about a specific memory type, go to the respective sec-
tion in this chapter.
Table 1-1. EZ-Board Internal Memory Map
Start Address
0xEF00 0000
0xEF00 8000
0xFF80 0000
0xFF80 4000
0xFF80 8000
0xFF90 0000
0xFF90 4000
0xFF90 8000
0xFFA0 0000
0xFFA0 4000
0xFFA0 8000
0xFFA1 0000
0xFFA1 4000
0xFFB0 0000
ADSP-BF518F EZ-Board Evaluation System Manual
Using ADSP-BF518F EZ-Board
Content
BOOT ROM (32K BYTE)
Reserved
DATA BANKA SRAM (16K BYTE)
DATA BANKA SRAM/CACHE (16K BYTE)
Reserved
DATA BANKB SRAM (16K BYTE)
DATA BANKB SRAM/CACHE (16K BYTE)
Reserved
INSTRUCTION BANK A SRAM (16K BYTE)
INSTRUCTION BANK B SRAM (16K BYTES)
Reserved
INSTRUCTION BANK C SRAM/CACHE (16K BYTE)
Reserved
SCRATCHPAD SRAM (4K BYTE)
Table 1-1. The inter-
Table 1-2. For
