User Guide EVAL-ADGM1144
EVAL-ADGM1144SDZ BLOCK DIAGRAM AND DESCRIPTIONS

MEMORY MAP

Click Proceed to Memory Map for full accessibility to all of the
registers (see Figure 5). This access allows registers to be edited at
a bit level (see Figure 6). The bits shaded in dark gray in Figure 6
are read only bits and cannot be accessed from ACE, and all other
bits are toggled. Clicking the Apply Changes button transfers data
to the ADGM1144.
All changes made in the memory map correspond to the block
diagram. For example, if the internal register bit is enabled, the
bit displays as enabled in the block diagram. Any bits or registers
that are bold in Figure 6 are modified values that have not been
transferred to the EVAL-ADGM1144SDZ. Click Apply Changes to
transfer data to the EVAL-ADGM1144SDZ.
Figure 6. ADGM1144 Memory Map
