Analog Devices EZ-Board ADSP-BF518F Manual page 73

Ref. Qty. Description
28 1 ADP1610
MSOP8
29 1 DIP3 SWT015
30 1 DIP8 SWT016
31 6 DIP6 SWT017
32 7 DIP4 SWT018
33 12 SMA XPINS
CON043
34 1 DB9 9PIN
CON038
35 2 DIP2 SWT020
36 4 IDC 2X1
IDC2X1
37 5 IDC 2X1
IDC2X1
38 13 IDC 3X1
IDC3X1
39 1 3A RESETABLE
FUS004
40 24 IDC
2PIN_JUMPER_
SHORT
41 1 PWR .65MM
CON045
42 2 3.5MM
DUAL_STEREO
CON050
43 1 SD_CONN 9PIN
CON051
ADSP-BF518F EZ-Board Evaluation System Manual
ADSP-BF518F EZ-Board Bill Of Materials
Reference Manufacturer
Designator
VR2 ANALOG
DEVICES
SW19 DIGI-KEY
SW20 C&K
SW15-18,SW22- CTS
23
SW3-8,SW10 ITT
J7,J16-26 JOHNSON
COMP
J2 NORCOMP
SW2,SW21 C&K
P8-11 FCI
JP3,JP11-14 FCI
JP15,JP17-28 FCI
F1 TYCO
SJ1-24 DIGI-KEY
J3 CUI
J4-5 SWITCHCRAFT
J13 DIGI-KEY
Part Number
ADP1610ARMZ-R7
CKN6114-ND
TDA08H0SB1
218-6LPST
TDA04HOSB1
142-0701-201
191-009-213-L-571
CKN9064-ND
90726-402HLF
90726-402HLF
90726-403HLF
SMD300F-2
S9001-ND
045-0883R
35RAPC7JS
401-1954-ND
A-3
