Product Overview
• Analog audio interface
Analog Devices SSM2603 low-power audio codec
One stereo
One headphone
One input
One input stereo
• Ethernet interface
National Semiconductor DP83848 PHY device
10-BaseT and 100-BaseTX
Auto-MDIX
• ADC interface
Analog Devices AD7266 2 MSPS, 12-bit, 3-channel SAR
analog-to-digital converter
• Thumbwheel
Panasonic EVQ-WKA001 rotary encoder
• Universal asynchronous receiver/transmitter (UART)
ADM3202 RS-232 line driver/receiver
DB9 female connector
• LEDs
Five LEDs: one board reset (red), three general-purpose
(amber), one configurable ethernet LEDs (amber) and one
power (green)
xiv
jack
LINE OUT
LINE IN
jack
MIC
LINE IN
ADSP-BF518F EZ-Board Evaluation System Manual
jack
