and
UART0 UART1
For more information, see "Expansion Interface II Connectors (P2 and
P4)" on page 2-23.
Example programs are included in the EZ-Board installation directory to
demonstrate UART and RS-232 operations.
For more information on the UART interface, refer to the ADSP-BF51x
Blackfin Processor Hardware Reference.

RTC Interface

The ADSP-BF518F processor has a real-time clock (RTC) and a watchdog
timer. Typically, the RTC interface is used to implement a real-time
watchdog or a life counter of the time elapsed since the last system reset.
The EZ-Board is equipped with a Panasonic CR1632 lithium coin and 3V
battery supplying 125 mAh. The 3V battery and 3.3V supply of the board
connect to the
powered, the RTC circuit uses the board power to supply voltage to the
pin. When the EZ-Board is not powered, the RTC circuit uses the
RTC
lithium battery to maintain power to the
mylar, the battery lasts for about one year with the EZ-Board unpowered.
Example programs are included in the EZ-Board installation directory to
demonstrate the RTC features.
The EZ-Board is shipped with a protective Mylar sheet placed
between the coin battery and positive pin of the battery holder.
Remove the Mylar sheet before using the RTC in the processor.
For more information on the RTC and watchdog timer, refer to the
ADSP-BF51x Blackfin Processor Hardware Reference.
ADSP-BF518F EZ-Board Evaluation System Manual
are connected to the expansion interface II connectors.
power pin of the processor. When the EZ-Board is
RTC
Using ADSP-BF518F EZ-Board
pin. After removing the
RTC
1-19
