Memory Map
Memory Map
The ADSP-21161N processor includes 1 MB of internal SRAM for pro-
gram storage or data storage. The configuration of internal SRAM is
detailed in the ADSP-21161 SHARC Processor Hardware Reference.
The ADSP-21161N EZ-KIT Lite board contains 512K x 8-bits of exter-
nal flash memory. The flash memory connects to the processors's
memory select pins. The flash memory can be accessed in either the
~BMS
boot memory space or the external memory space. The external memory
interface also connects to three 8M x 16-bit synchronous dynamic random
access memory (SDRAM). The SDRAM memory connects to the
memory select pin.
Table 1-1. EZ-KIT Lite Evaluation Board Memory Map
Start Address
0x0000 0000
0x0002 0000
Internal
0x0002 8000
Memory
0x0004 0000
0x0005 0000
0x0008 0000
0x000A 0000
0x0010 0000
0x0020 0000
External
0x0400 0000
Memory
0x0800 0000
0x0C00 0000
1-8
www.BDTIC.com/ADI
End Address
0x0001 FFFF
0x0002 1FFF
0x0002 9FFF
0x0004 3FFF
0x0005 3FFF
0x0008 7FFF
0x000A 7FFF
0x001F FFFF
0x009F FFFF
0x0407 FFFF
0x0BFF FFFF
0x0FFF FFFF
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Content
IOP registers (internal)
Block 0 long word addressing
Block 1 long word addressing
Block 0 normal word addressing
Block 1 normal word addressing
Block 0 short word addressing
Block 1 short word addressing
Multiprocessor memory space
External memory space bank 0 (SDRAM)
External memory space bank 1 (flash)
External memory space bank 2
External memory space bank 3
and
~MS1
~MS0
