Ref. Qty. Description
44 2 RJ45 8PIN
CON_RJ45_12P
45 3 MOMENTARY
SWT024
46 1 ROTARY_ENC_
EDGE SWT025
47 1 QMS 52x2
QMS52x2_SMT
48 2 IDC 25x2
IDC25x2_SMTA
49 1 IDC 35x2
IDC35x2_SMTA
50 1 IDC 7x2
IDC7x2_SMTA
51 1 BATT_HOLDER
16MM
BATT_COI
52 2 IDC 2X1
IDC2X1_SMT
53 1 ROTARY
SWT027
54 3 YELLOW
LED001
55 2 100 1/10W 5%
0805
56 11 600 100MHZ
200MA 0603
57 2 600 100MHZ
500MA 1206
58 2 10UF 16V 20%
CAP002
A-4
Reference
Designator
J14-15
SW11-13
SW14
J1
P2,P4
P3
P1
J12
JP4,JP16
SW1
LED1-3
R165,R167
FER2-9,FER12-
14
FER15-16
CT1-2
