Product Overview
The board features:
• Analog Devices ADSP-BF518F Blackfin processor
Core performance up to 400 MHz
External bus performance up to 80 MHz
176-pin LQFP package
25 MHz crystal
• Programmable VDDINT core power
Analog Devices AD5258 TWI digital potentiometer
Analog Devices ADP1715 low dropout linear regulator
•
Synchronous dynamic random access memory (SDRAM)
Micron MT48LC32M16A2TG – 64 MB (32M x 16-bits)
• Parallel flash memory
Numonyx M29W320EB – 4 MB (2M x 16-bits)
• eMMC flash memory
Micron MTFC2GDKDM – 2 GB
• SPI flash memory
Numonyx M25P16 – 16 Mb
ADSP-BF518F EZ-Board Evaluation System Manual
Preface
xiii
