• Push buttons
Three push buttons: one reset, two programmable flags with
debounce logic
• Expansion interface II
Next generation of the expansion interface design, provides
access to most of the ADSP-BF518F processor signals
• Land grid array
Easy probing of all port pins and most EBIU signals
• Other features
JTAG ICE 14-pin header
Blackfin power measurement jumpers
For information about the hardware components of the EZ-Board, refer
to "ADSP-BF518F EZ-Board Hardware Reference" on page

Purpose of This Manual

The ADSP-BF518F EZ-Board Evaluation System Manual provides instruc-
tions for installing the product hardware (board). The text describes
operation and configuration of the board components and provides guide-
lines for running your own code on the ADSP-BF518F EZ-Board.
Finally, a schematic and a bill of materials are provided for reference.
The product software installation is detailed in the VisualDSP++ Installa-
tion Quick Reference Card.
ADSP-BF518F EZ-Board Evaluation System Manual
Preface
2-1.
xv
