D1FF1XXX • D1XX3Y02
D1FF1XXX
Explanation: Dump complete
Response:
1. Go to Checkout procedure.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
D1XX3YYY
Explanation: Platform dump status codes are described in D1xx3y01 to D1xx3yF2 Service processor dump codes
Response:

D1xx3yzz service processor dump codes:

These D1xx3yzz service processor dump codes use the format: D1xx3yzz, where xx indicates the cage or
node ID that the dump component is processing, y increments from 0 to F to indicate that the system is
not hung, and zz indicates the command being processed.
The D1xx3yzz dump codes below are the progress codes that might be displayed during the power-on
self-test (POST), along with suggested actions to take if the system hangs on the progress code. Only
when you experience a hang condition should you take any of the actions described for a progress code.
If the system hangs on a progress code, follow the suggested actions in the order in which they are listed
until the problem is solved. If an action solves the problem, you can stop performing the remaining
actions. See Chapter 7, "Parts listing for IBM Flex System p270 Compute Node," on page 95 to determine
which components are CRUs and which components are FRUs.
D1XX3Y01
Explanation: Get SCOM
Response:
1. Go to Checkout procedure.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
D1XX3Y02
Explanation: Get scan ring
Response:
1. Go to Checkout procedure.
2. Replace the system-board, as described in Replacing the system-board and chassis assembly.
