Component
Memory
Storage devices
USB 3.0 ports
Oracle Database Appliance X9-2 Series Components and Capabilities
Oracle Database
Appliance X9-2S
256 GB – eight 32 GB low-
voltage DDR4 RDIMMs
rated at 3200 MT/sec.
Optional memory
expansion to 512 GB. See
Optional Component
Installation.
The server includes:
• Two internal 240 GB
M.2 SATA SSDs
reserved for operating
system storage and
system booting
• Two 2.5-inch 6.8 TB
NVMe SSDs in front
slots 0 and 1
No additional storage
options are supported.
One external port at the
back of the server.
Oracle Database
Appliance X9-2L
512 GB – sixteen 32 GB
low-voltage DDR4 RDIMMs
rated at 3200 MT/sec.
Optional memory
expansion is available to 1
Optional
TB. See
Component Installation.
The server includes:
• Two internal 240 GB
M.2 SATA SSDs
reserved for operating
system storage and
system booting
• Two 2.5-inch 6.8 TB
NVMe SSDs in front
slots 0 and 1
Up to ten optional NVMe
SSDs can be added. See
Optional Component
Installation.
One external port at the
back of the server.
Chapter 2
Oracle Database
Appliance X9-2-HA
512 GB – sixteen 32 GB
low-voltage DDR4 RDIMMs
rated at 3200 MT/sec per
server node.
Optional memory
expansion to 1 TB per
node. Both server nodes
must have the same
amount of memory. See
Optional Component
Installation.
Each server node includes:
• Two internal 240 GB
M.2 SATA SSDs
reserved for operating
system storage and
system booting
The 4RU storage shelf
includes one of the
following available
configurations:
• Partially populated
storage shelf with
either six, twelve, or
eighteen 2.5-inch 7.68
TB SAS SSDs (in 3.5-
inch mounting
brackets)
• Twenty-four 2.5-inch
7.68 TB SAS SSDs (in
3.5-inch mounting
brackets) in slots 0-23
• Six 2.5-inch 7.68 TB
SAS SSDs (in 3.5-inch
mounting brackets) in
slots 0-5 and eighteen
3.5-inch 18 TB SAS
HDDs in slots 6-23
For a partially populated
storage shelf, optional 7.68
TB SAS SSDs, or 18 TB
SAS HDDs can be added.
Optional Component
See
Installation.
One external port at the
back of each server node.
