Component
Service Processor (SP)
Power supplies
Cooling fans
Operating system
Management software
Oracle Database Appliance X9-2S/X9-2L Front and Back
Panels
See views and descriptions of front and back panel features for Oracle Database
Appliance X9-2S/X9-2L.
This section describes Oracle Database Appliance X9-2S/X9-2L front and back
panels. If you have some other Oracle Database Appliance model, select the
appropriate link listed in

Oracle Database Appliance X9-2S/X9-2L Front and Back Panels

Oracle Database
Appliance X9-2S
Each server has a service
processor with the following
features:
• Includes the
Baseboard
Management
Controller (BMC),
which supports the
industry-standard
Intelligent Platform
Management Interface
(IPMI) feature set.
• Supports remote
KVMS over IP.
• Supports Ethernet
access to SP through
a dedicated
10/100/1000Base-T
management port and
optionally through one
of the host GbE ports
(sideband
management).
Two hot-pluggable power
supplies.
Four 80-mm, hot-pluggable
fan modules per server for
chassis cooling. Each fan
module contains two
counter-rotating fan pairs
(four rotors total).
Each power supply has its
own cooling fans.
Oracle Linux.
Oracle Integrated Lights
Out Manager (ILOM) 5.1.
Overview of Oracle Database
Oracle Database
Appliance X9-2L
Each server has a service
processor with the following
features:
• Includes the
Baseboard
Management
Controller (BMC),
which supports the
industry-standard
Intelligent Platform
Management Interface
(IPMI) feature set.
• Supports remote
KVMS over IP.
• Supports Ethernet
access to SP through
a dedicated
10/100/1000Base-T
management port and
optionally through one
of the host GbE ports
(sideband
management).
Two hot-pluggable power
supplies.
Four 80-mm, hot-pluggable
fan modules per server for
chassis cooling. Each fan
module contains two
counter-rotating fan pairs
(four rotors total).
Each power supply has its
own cooling fans.
Oracle Linux.
Oracle Integrated Lights
Out Manager (ILOM) 5.1.
Appliance.
Chapter 2
Oracle Database
Appliance X9-2-HA
Each server node has a
service processor with the
following features:
• Includes the
Baseboard
Management
Controller (BMC),
which supports the
industry-standard
Intelligent Platform
Management Interface
(IPMI) feature set.
• Supports remote
KVMS over IP.
• Supports Ethernet
access to SP through
a dedicated
10/100/1000Base-T
management port and
optionally through one
of the host GbE ports
(sideband
management).
Two hot-pluggable power
supplies per server node
and per storage shelf.
Four 80-mm, hot-pluggable
fan modules per server
node for chassis cooling.
Each fan module contains
two counter-rotating fan
pairs (four rotors total).
Each power supply (server
node and storage shelf)
has its own cooling fans.
Oracle Linux.
Oracle Integrated Lights
Out Manager (ILOM) 5.1.
