Callout
8
9
10
11
12
13
14
15
16
17
18
19
20
Oracle Database Appliance X9-2S/X9-2L Front and Back Panels
Description
PCIe card slot 4:
• Oracle Database Appliance X9-2S: filler
panel
• Oracle Database Appliance X9-2L: filler
panel, or optional Oracle Dual Port 25Gb
Ethernet Adapter, or optional Oracle
Quad Port 10GBase-T Adapter
PCIe card slot 5: filler panel
Not used
SER MGT port: RJ-45 serial port used to
connect to the Oracle ILOM service processor
NET MGT port: 10/100/1000Base-T network
interface port with RJ-45 connector used to
connect to the Oracle ILOM service processor
100/1000BASE-T network interface port with
RJ-45 connector: NET 0
USB 3.0 connector
System status indicators: Locate LED: white,
Service Required LED: amber, Power/OK
LED: green
PCIe card slot 6: public network interface card
• Oracle Dual Port 25Gb Ethernet Adapter
[16a]
--or--
• Oracle Quad Port 10GBase-T Adapter
[16b]
PCIe card slot 7:
• Oracle Database Appliance X9-2S: filler
panel, or optional Oracle Dual Port 25Gb
Ethernet Adapter, or optional Oracle
Quad Port 10GBase-T Adapter
• Oracle Database Appliance X9-2L: filler
panel
PCIe card slot 8:
• Oracle Database Appliance X9-2S: filler
panel, or optional Oracle Dual Port 25Gb
Ethernet Adapter, or optional Oracle
Quad Port 10GBase-T Adapter
• Oracle Database Appliance X9-2L: filler
panel, or optional Oracle Dual Port 25Gb
Ethernet Adapter, or optional Oracle
Quad Port 10GBase-T Adapter
PCIe card slot 9: filler panel
PCIe card slot 10:
• Oracle Database Appliance X9-2S: filler
panel
• Oracle Database Appliance X9-2L: Oracle
Retimer Card
