Changing Software
Feature Level

Dial a Lower Level

Exchange the EEPROM

Changing Remote
Control Function
Revision J
CONFIGURATION: Advanced User Procedures
The highest software feature level (i.e. 7015, 7020, 7025, 7030) of a
monitor is programmed into the serial EEPROM of the main processor
PCB. There are two ways of changing the software feature level. One way
is to dial a lower level and the other is to exchange the serial EEPROM
on the main processor PCB. The EEPROM should only be changed by
authorized personnel.
NOTE: The user may only change the feature level to a lower level than
the level installed at the factory.
There are times when a monitor may need to function at a lower feature
level than it was originally programmed at.
1. To access FEATURE LEVEL option, execute the following menu
sequence starting from the MAIN menu:
MONITOR SETUP
SERVICE MODE
Password
Enter day and month from monitor screen with leading zeros.
(July 4 = 0407)
MENU SETUP
SOFTWARE LEVEL
2. Rotate Trim Knob control to select the type of environment the
monitor will be used in.
3. Press the Trim Knob control to exit. Your selection will be displayed
at the top of the screen after the time.
To change the highest software feature level available in a monitor, you
must purchase the serial EEPROM U9 which contains the software
feature level you want.
Do the following to change the serial EEPROM in the monitor.
1. Contact your Monitoring Sales Representative for the current part
number and order the part.
2. Refer to the "Disassembly Guidelines" in Chapter 7:"Monitor
Assembly" of this manual.
There are three types of remote control available. In order to change the
function of a standard remote control to a neonatal or general operating
room (OR) remote control, a specific update kit and instructions are
required. Both kits listed below include the instructions, pn 404183-210.
Operating Room Remote Control Update Kit
Neonatal Remote Control Update Kit
Solar 7000/8000/View Patient Monitor
414993-001
Remote Control Update Kits
Item Part Number
412977-002
412977-003
6-13
