GE Solar 7000 Service Manual page 130

Are graphs and
alarms printed at
the desired
location?
Does the remote
control activate the
display?
Is the quality of the
Solar 7000 remote
display good?
End
4-44
TROUBLESHOOTING: Troubleshooting Procedure
Troubleshooting Chart
Try one of the following solutions.
1. Verify paper in central station writer is correct side up.
2. If the monitor was moved from one care unit to another, reprogram the graph
destinations.
Watch for misspelling or inclusion of a space character in the name.
Make sure that the care unit name programmed into the monitor and central
station match exactly.
Typically, the care unit name for a monitor is not shown on the central
station display of a patient's data. Only the bed number is shown. If the care
unit name for a monitor does not match the central station care unit name,
then the monitor identification changes. The monitor identifier shows the
care unit name followed by a vertical slash (|) and then the bed number. The
solution is to modify the monitor care unit name to match the central
station's care unit name.
3. If a stand-alone DDW is being used, you should set the graphs to BEDSIDE
for both graphing locations.
At times, the remote control will 'lock up.' This is caused by an interruption of
power to the remote control. Try one of the following solutions.
1. Check for a loose connection from the monitor to the remote control.
2. Try a different Tram-net hub port.
3. Disconnect and securely reconnect the remote control from the monitor to
reset the remote control.
4. Replace remote control with a known good one.
5. Swap main processor PCB in patient monitor with a known good one.
The monitor display is fine, but the remote display is distorted. Try one of the
following solutions.
1. Check for a loose connection from the monitor to the remote display.
2. If the remote display was first used with a Tramscope monitor and then
connected to a Solar 7000 monitor, a cable adapter, pn 405947-002, is
required between the monitor and the remote display.
3. Swap cable adapter or cable between monitor and remote display with a
known good one.
4. Ensure RGB and SYNC inputs are 75Ω terminated (LOW). (Tramscope
monitors support unterminated (HIGH) impedance mode.
This is the extent of troubleshooting steps developed at this time.
Solar 7000/8000/View Patient Monitor
414993-001
Revision J
