Table 3: User Power Port Pinout
Pinout Sourc
e
VBAT 300
1
2 12V 300
3 GND
4 5V 500
5 3V3 250
6 GND
Molex Picoblade 6-Pin cable assembly
The two connectors are both
needed to use these connectors are
Molex PicoBlade: Connector 0532610671 (left) and Cable 0151340602 (right)
Max current output (mA)
6-Pin Molex PicoBlade P/N
P/N
Fuse Hold at (mA)
350
350
500
300
0532610671. The cable assembly
0151340602.
