Peel-Off, cont'd.
5 b
...hook a new roll of direct thermal labels on the
paper supply hanger and adjust the guide so the
label roll comes in flush with the wall.
7
Thread the backing paper around the tear-off
edge and back under the print unit and guide
Intermec EasyCoder F2 – Installation & Operation Ed. 1
shaft.
6
Remove labels from the first 50 cm (20") of the
web. Thread the label web through the print unit
and push it inwards as far as it will go.
8
Insert the end of the backing paper under the
lip of the rewinder, then rotate the rewinder
counter-clockwise a few turns.
