Paper Roll Size

Intermec EasyCoder F2 – Installation & Operation Ed. 1
Core
Diameters: 38 – 40 mm (1.5") or 76.2 mm (3")
Width: Must not protrude outside the web.
The web must be wound up on the core in such a way that the
printer can pull the end of the web free.
Roll
Max. diameter (internal supply only):
- Position 1
- Position 2
- Position 3
Max. width:
Min. width (standard):
Min. width (Quick-Load):
Max. web thickness:
The maximum recommended web thickness is 175 m. A thicker
web may be used, but print quality will be reduced. Web stiffness is
also important and must be balanced against web thickness to main-
tain print quality.
Paper rolls fitted inside the printer should be wound with the print-
able side facing outwards.
The paper supply must not be exposed to dust, sand, grit, etc. Any
hard particles, however small, can damage the printhead.
Appendix 2 Media Specifications
152 mm (6.00")
213 mm (8.38")
203 mm (8.00")
60 mm (2.36")
25 mm (1.00")
40 mm (1.57")
175 m (0.007")
88
